The SDC12™ features 12 DMX channels, DIP switches to set a starting DMX channel, a master dimmer fader, on/off switch, 3-pin and 5-pin XLR output, and operates via an external 12VDC power supply (included) or a 9VDC battery (not included). Great handheld device for product demos or manual control of LED or conventional fixtures. Can be wall mounted for permanent installations.

Features

 12 DMX Channels Faders
 Master Dimmer Fader
 Portable Handheld Or Wall Mountable
 Operates via 12VDC Power Supply (Included) Or
 9VDC Battery (Not Included)

Specifications

CONTROL / CONNECTIONS
 DIP Switches To Set Starting DMX Channel
 3pin & 5pin DMX Outputs
 On/Off Switch
 LED Channel Bank Indicator
 DC 12V Power Supply Input

 SIZE / WEIGHT
 Length: 7.5” (191mm)
 Width: 5.9” (149mm)
 Height: 1.6” (41mm)
 Weight: 2.0 lbs. (0.9kg)

 ELECTRICAL
 DC 12V 500mA min OR 9V Battery (Not Included)

 APPROVALS / RATINGS
 CE | RoHs Compliant

 INCLUDED ACCESSORIES
 12V Power Supply
